We stock VATAN Cables, medium voltage XLPE insulated flat steel wire armored three core cable with copper conductor
- Producer: VATAN KABLO / TURKEY
- Cable Code: N2XSEYFGbY
- Applied Standards: IEC 60502-2
- Voltage Rate (U0) (kV): 8,70
- Voltage Rate (Um) 15,00
- Max Operating Voltage (Um) (kV): 17,50
| VATAN High Quality Power Cables | ||||
|---|---|---|---|---|
| INSULATION | ||||
| Material: | XLPE | |||
| Nominal Thickness (mm): | 4,50 | |||
| Minimum Thickness (mm): | 3,95 | |||
| Outer Diameter of Insulation (Approx.) (mm): | 21,50 | |||
| ARMOUR | ||||
| Material: | Galvanized Flat Steel Wire | |||
| Wire Diameter X Diameter: | 42x 4,0X0,80 | |||
| Thickn. of Galvanize Coat. of Steel Tape: | 0,30mm | |||
| Width of Steel Tape: | 20,00mm | |||
| Binding Ratio(%): | ||||
| STRUCTURAL PROPERTIES CONDUCTOR | ||||
| Material: | Copper | |||
| Cross-sectional Area (mm²) : | 95 | |||
| Number of Wires : | 19×2,49 | |||
| Type of Stranding : | CIRCULAR COMPACTED | |||
| Outer Diameter of Strand (mm) : | 11,50 | |||
| Core Number 3 | ||||
| INNER SEMICONDUCTING SCREEN | ||||
| Material: | Semiconductive XLPE | |||
| Nominal Thickness : | 0,50mm | |||
| Minimum Thickness : | 0,30mm | |||
| Outer Diameter of Screen (Approx.) (mm) | ||||
| OUTER SEMICONDUCTING SCREEN | ||||
| Material: | Semiconductive XLPE | |||
| Nominal Thickness : | 0,50mm | |||
| Minimum Thickness : | 0,30mm | |||
| S.C. Tape: | Yes | |||
| Tape Thickness | 0,30mm | |||
| INNER SHEATH (Filler +Bedding) | ||||
| Filler Material: | PVC | |||
| Nominal Thickness : | 1,60mm | |||
| Bedding Material : | PVC | |||
| Nominal Thickness: | 1,70mm | |||
| Minimum Thickness | 1,43mm | |||
| OUTER SHEATH | ||||
| Material: | PVC | |||
| Color : | Red or Black | |||
| Nominal Thickness : | 3,00mm | |||
| Minimum Thickness: | 2,60mm | |||
| Minimum Thickness | 1,43mm | |||
